PCB Mounting Straight Pin Header , 1x5 pin Pitch 2.54mm Pin Header

Basic Information
Place of Origin: China
Brand Name: Sinrui
Certification: RoHS,REACH, ISO9001:2015
Model Number: SR-M20S05AS-XX
Minimum Order Quantity: 4000pcs
Price: please contact us
Packaging Details: export standard packing
Delivery Time: L/C, T/T
Payment Terms: T/T
Supply Ability: 500000 per 14 days
Pitch: 2.54mm Pin Numbers: 5Pins
Row: Single Row Plastics Height: 2.0mm
Pin Material: Brass Plastics Material: PA9T
Rated Current: 3.0Amp Rated Voltage: 550V AC / Min,
High Light:

2mm pitch pin header


arduino male header pins

Products Name: PCB Mounting Straight Type Pin Header, 1x5pin pitch 2.54mm Pin Header


Products Descrption:

this Pin Header is with pitch 2.54mm, dual row with 12 pin numbers. with a specified pin length and 0.64mm square pins that it can afford an AMP of current transmission. It usually match with a same pitch and pin number of Female Header so as to form as board to board connection, or match with a wire haress forming as wire to board connection, or it can directly soldered in two PCBs.


Its pitch, pin number, mounting type, length can be customized according to customer application, like:

Pitch can be optional as 0.8mm,1.0mm, 1.27mm, 2.0mm, 2.54mm,3.96mm,etc.

And it can be  single row, dual row or triple row.

Mounting type can be customized to be SMT(vertical or side entry), DIP throught PCB(vertial or side entry).


Common Application:

we produce and supply in hugh volumn for consuming electronics of consumer catagory, Telecommunication, industrial control, meters, medical, aviation and millitary.

Items Material Plating
Contact Brass Gold
Insulator PA9T N/A


Description Value
Type Board to Board Connector
Gender Male Header
Structure Straight
Mounting type Straight for PCB Mounting
Current rated 3.0 Amp per contact
Voltage Rated 550V AC/ min.
Contact Resistance < 20m ohm per contact
Insulation resistance > 1000m ohm
Withstanding Voltage 1000V DC/AC
Temperature Operation -40 C° to +105 C°
Processing(Soldering) Temperature

230C° for 30~60 seconds,

(260C° for 5 seconds)




PCB Mounting Straight Pin Header , 1x5 pin Pitch 2.54mm Pin Header 0


Function: It provides an electric current connection between board to board or board to wires.
